Drawing Graph in Android

Hello guys, whats up?? Today in this blog we are going to see how to draw graphs in Android. For this purpose we are going to use a library called as "achartengine" . So , lets get started.

Download

1) First of all  create an Android Application Project.

2) Next go to "res/alyout/activity_main.xml" and create a LinearLayout there.

activity_main.xml

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/label"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical"
    android:paddingBottom="@dimen/activity_vertical_margin"
    android:paddingLeft="@dimen/activity_horizontal_margin"
    android:paddingRight="@dimen/activity_horizontal_margin"
    android:paddingTop="@dimen/activity_vertical_margin"
    tools:context=".MainActivity" >

</LinearLayout>

3) Now go to http://www.achartengine.org/content/download.html and download "achartengine" library from there.

4) Right click on the project file in eclipse and go to properties->Java Bild Path-> Libraries-> Export External Jar files and select the downloaded "achartengine" library from there.

5) Now go to "src/your_package_name/MainActivity.java" and paste the following code there.

MainActivity.java

import org.achartengine.ChartFactory;
import org.achartengine.GraphicalView;
import org.achartengine.chart.PointStyle;
import org.achartengine.model.*;
import org.achartengine.renderer.XYMultipleSeriesRenderer;
import org.achartengine.renderer.XYSeriesRenderer;

import android.os.Bundle;
import android.app.Activity;
import android.app.Fragment;
import android.graphics.Paint.Align;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.LinearLayout;

public class MainActivity extends Activity {

    private GraphicalView mChart;
    private XYSeriesRenderer mCurrentRenderer;
    private XYSeriesRenderer mCurrentRenderer1;
    private XYSeriesRenderer mCurrentRenderer2;
    private XYSeries mCurrentSeries;
    private XYSeries mCurrentSeries1;
    private XYSeries mCurrentSeries2;
    private XYMultipleSeriesDataset mDataset = new XYMultipleSeriesDataset();
    private XYMultipleSeriesRenderer mRenderer = new XYMultipleSeriesRenderer();
    private View rootView = null;

    private void addSampleData1() {
        double[] arrayOfDouble = { 20.0D, 30.0D, 67.0D, 80.0D, 85.0D, 94.0D,
                99.0D, 100.0D, 102.0D, 104.0D, 106.0D, 108.0D };
        for (int i = 0;; i++) {
            if (i >= 12) {
                return;
            }
            this.mCurrentSeries.add(i, arrayOfDouble[i]);
        }
    }

    private void addSampleData2() {
        double[] arrayOfDouble = { 30.0D, 55.0D, 80.0D, 90.0D, 91.0D, 100.0D,
                102.0D, 105.0D, 110.0D, 115.0D, 120.0D, 125.0D };
        for (int i = 0;; i++) {
            if (i >= 12) {
                return;
            }
            this.mCurrentSeries1.add(i, arrayOfDouble[i]);
        }
    }

    private void addSampleDatamid() {
        double[] arrayOfDouble = { 25.0D, 50.0D, 75.0D, 85.0D, 87.0D, 99.0D,
                100.0D, 105.0D, 106.0D, 107.0D, 108.0D, 109.0D };
        for (int i = 0;; i++) {
            if (i >= 12) {
                return;
            }
            this.mCurrentSeries2.add(i, arrayOfDouble[i]);
        }
    }

    private void initChart() {
        this.mCurrentSeries = new XYSeries("Min Price");
        this.mCurrentSeries1 = new XYSeries("Max Price");
        this.mCurrentSeries2 = new XYSeries("Predicted Price");
        this.mDataset.addSeries(this.mCurrentSeries);
        this.mDataset.addSeries(this.mCurrentSeries1);
        this.mDataset.addSeries(this.mCurrentSeries2);
        this.mCurrentRenderer = new XYSeriesRenderer();
        this.mCurrentRenderer1 = new XYSeriesRenderer();
        this.mCurrentRenderer2 = new XYSeriesRenderer();
        this.mCurrentRenderer.setColor(-16776961);
        this.mCurrentRenderer1.setColor(-16711936);
        this.mCurrentRenderer2.setColor(-65536);
        this.mCurrentRenderer.setPointStyle(PointStyle.SQUARE);
        this.mCurrentRenderer1.setPointStyle(PointStyle.CIRCLE);
        this.mCurrentRenderer2.setPointStyle(PointStyle.DIAMOND);
        this.mCurrentRenderer.setFillPoints(true);
        this.mCurrentRenderer1.setFillPoints(true);
        this.mCurrentRenderer2.setFillPoints(true);
        this.mRenderer.addSeriesRenderer(this.mCurrentRenderer);
        this.mRenderer.addSeriesRenderer(this.mCurrentRenderer1);
        this.mRenderer.addSeriesRenderer(this.mCurrentRenderer2);
        this.mRenderer.setXTitle("month");
        this.mRenderer.setYTitle("price");
        this.mRenderer.setZoomButtonsVisible(true);
        this.mRenderer.setPointSize(2.0F);
        this.mRenderer.setShowGridX(true);
        String[] arrayOfString = { "Jan", "Feb", "Mar", "Apr", "May", "Jun",
                "Jul", "Aug", "Sep", "Oct", "Nov", "Dec" };
        for (int i = 0;; i++) {
            if (i >= arrayOfString.length) {
                this.mRenderer.setXLabels(0);
                this.mRenderer.setXLabelsAlign(Align.CENTER);
                return;
            }
            this.mRenderer.addTextLabel(i, arrayOfString[i]);
        }
    }

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

    }

    public void onResume() {
        super.onResume();
        LinearLayout localLinearLayout = (LinearLayout) findViewById(R.id.label);
        if (this.mChart == null) {
            initChart();
            addSampleData1();
            addSampleData2();
            addSampleDatamid();
            this.mChart = ChartFactory.getLineChartView(this, this.mDataset,
                    this.mRenderer);
            localLinearLayout.addView(this.mChart);
            return;
        }
        this.mChart.repaint();
    }

}

Now we are done. Post your questions in the comment. I will be happy to answer those.
